Interactive visualization and evaluation of 3D MAGMASOFT® results

MAGMAinteract® is a software for the visualization of MAGMASOFT® results. This free 3D-viewer enables the intuitive display of information exported from MAGMASOFT® (starting from release 5.4.1). MAGMAinteract® promotes communication between all parties interested in MAGMASOFT® results within an organization, as well as with suppliers and customers. This quick and easy presentation of information creates the basis for sound decisions.

Key functionality of MAGMAinteract®:

  • Interactive visualization of 3D MAGMASOFT® results
  • Animation of mold filling, solidification pattern and tracer particles
  • Visualization of mold filling, solidification and distortion as well as quality criteria including results on pre-defined cross-sections
  • Interactive evaluation of designs of experiments in parallel coordinate diagrams

Example: Investment Casting

¿Necesitas de ayuda?

Si tiene preguntas sobre MAGMAinteract ® o necesita soporte de instalación, comuníquese con su equipo de soporte:

+55 (11) 3090-3139

Filling

Filling

Filling

MAGMAinteract®

Mold Filling: Melt indicated by colour when entering cavities from different gates

Mold Filling: Melt Temperature Distribution during Filling

Solidification: Local Solidification Times; clipping display

Download the following files for your own MAGMAinteract® installation
